Especificações Técnicas

ELECTRICAL SPECIFICATIONS   FREQUENCY 5150-5850 MHZ BAND WIDTH 700 MHZ GAIN 28.5 DBI POLARIZATION HORIZONTAL AND VERTICAL HORIZONTAL BEAM WIDTH 5° VERTICAL BEAM WIDTH 5° FRONT TO BACK RATIO - 35 DB ISOLATION - 28 DB IMPEDANCE 50 OHM MAX. INPUT POWER 100 WATTS VSWR     MECHANICAL SPECIFICATIONS   WEIGHT 12.1 LBS. (5.5 KG) DIAMETER 23.6 IN. (600 MM) MOUNTING 1.5 (38MM) TO 3 (76MM) DIA. MASTS OPERATING TEMPERATURE -40° C TO TO 85° C (-40° F TO 185° F) CONNECTORS (2) N-FEMALE ROHS COMPLIANT YES RADOME COVER PART NUMBER HGR-06     WIND LOADING DATA   WIND SPEED (MPH) LOADING   WITH RADOME 100 113 LB. 75 LB. 125 177 LB. 116 LB.     HG5158DP-29D ANTENA DIRECIONAL HYPERLINK 28DBI MAIORES DETALHES DE HG5158DP-29D NO SITE DO FABRICANTE: HTTP://WWW.HYPERLINKTECH.COM TAGS DE HG5158DP-29D: HG5158DP-29D, EQUIPAMENTOS WIRELESS, ANTENAS, HYPERLINK TECHNOLOGIES, 28DBI, 28 DBI, ANTENA 28 DBI, ANTENA 28DBI, HG5158DP29D, HG5158DP, HG5158DP 29D, HG5158DP/29D

Informações Adicionais
