Especificações Técnicas

SPECIFICATIONS   FREQUENCY 5470-5725 MHZ GAIN 21 DBI POLARIZATION HORIZONTAL OR VERTICAL HORIZONTAL BEAM WIDTH 10° VERTICAL BEAM WIDTH 13° FRONT TO BACK RATIO 25 DB IMPEDANCE 50 OHM MAX. INPUT POWER 100 WATTS VSWR < 1.5:1 AVG. WEIGHT 3.0 LBS. (1.4 KG) GRID DIMENSIONS 11.8 X 15.7 INCHES (300 X 400 MM) MOUNTING 2 IN. (50.8 MM) DIAMETER MAST MAX. OPERATING TEMPERATURE -40° C TO TO 85° C (-40° F TO 185° F) LIGHTING PROTECTION DC SHORT CONNECTOR N-FEMALE ROHS COMPLIANT YES     WIND LOADING DATA WIND SPEED (MPH) LOADING   100 10.0 LB. 120 15.6 LB.     HG5421G ANTENA DIRECIONAL HYPERLINK HG5421G MAIORES DETALHES DE HG5421G NO SITE DO FABRICANTE: HTTP://WWW.HYPERLINKTECH.COM TAGS DE HG5421G: HG5421G, EQUIPAMENTOS WIRELESS, ANTENAS, HYPERLINK TECHNOLOGIES, 21DBI, 21 DBI, ANTENA 21 DBI, ANTENA 21DBI

Informações Adicionais
