Especificações Técnicas

GENERAL INFORMATION PRODUCT TYPE :WIRELESS ACCESS POINTMANUFACTURER PART NUMBER :AIR-AP1231G-A-K9MANUFACTURER WEBSITE ADDRESS :WWW.CISCO.COM/WEB/CA/  MANUFACTURER :CISCO SYSTEMS, INCPRODUCT NAME :AIRONET 1231 WIRELESS ACCESS POINTPRODUCT LINE :AIRONETPRODUCT SERIES :1200 WIRELESS SPECIFICATIONS ANTENNA :2 X RP-TNC CONNECTORFREQUENCY BAND/BANDWIDTH :2.412 GHZ TO 2.462 GHZ IEEE 802.11B/G FCCRECEIVER SENSITIVITY :-95 DBM - 1MBPS IEEE 802.11B -91 DBM - 2MBPS IEEE 802.11B -89 DBM - 5.5MBPS IEEE 802.11B -90 DBM - 6MBPS IEEE 802.11G -84 DBM - 9MBPS IEEE 802.11G -88 DBM - 11MBPS IEEE 802.11B -82 DBM - 12MBPS IEEE 802.11G -80 DBM - 18MBPS IEEE 802.11G -77 DBM - 24MBPS IEEE 802.11G -73 DBM - 36MBPS IEEE 802.11G -72 DBM - 48MBPS IEEE 802.11G -72 DBM - 54MBPS IEEE 802.11G TRANSMISSION SPEED :54MBPSTRANSMIT POWER :30 MW IEEE 802.11G 15 DBM IEEE 802.11G 20 MW IEEE 802.11G 13 DBM IEEE 802.11G 10 MW IEEE 802.11G 10 DBM IEEE 802.11G 5 MW IEEE 802.11G 7 DBM IEEE 802.11G 1 MW IEEE 802.11G 0 DBM IEEE 802.11G ACCESS METHOD :CSMA/CAANTENNA RANGE :27 M@ 54MBPS INDOORS IEEE 802.11G 29 M@ 48MBPS INDOORS IEEE 802.11G 30 M@ 36MBPS INDOORS IEEE 802.11G 43 M@ 24MBPS INDOORS IEEE 802.11G 55 M@ 18MBPS INDOORS IEEE 802.11G 64 M@ 12MBPS INDOORS IEEE 802.11G 76 M@ 9MBPS INDOORS IEEE 802.11G 91 M@ 6MBPS INDOORS IEEE 802.11G 76 M@ 54MBPS OUTDOORS IEEE 802.11G 183 M@ 18MBPS OUTDOORS IEEE 802.11G 396 M@ 6MBPS OUTDOORS IEEE 802.11G CHANNELS :11 CHANNEL(S)OPERATING IEEE 802.11B/G AMERICAS 3 CHANNEL(S)NON-OVERLAPPING MODULATION :OFDM: BPSK @ 6 AND 9 MBPS QPSK @ 12 AND 18 MBPS 16-QAM @ 24 AND 36 MBPS 64-QAM @ 48 AND 54 MBPS DSSS: DBPSK @ 1 MBPS DQPSK @ 2 MBPS CCK @ 5.5 AND 11 MBPSTRANSMISSION SPEED DETAILS :1MBPS IEEE 802.11B 2MBPS IEEE 802.11B 5.5MBPS IEEE 802.11B 6MBPS IEEE 802.11G 9MBPS IEEE 802.11G 11MBPS IEEE 802.11B 12MBPS IEEE 802.11G 18MBPS IEEE 802.11G 24MBPS IEEE 802.11G 36MBPS IEEE 802.11G 48MBPS IEEE 802.11G 54MBPS IEEE 802.11G WIRELESS SECURITY :CISCO WIRELESS SECURITY SUITE INCLUDING: AUTHENTICATION: 802.1X SUPPORT INCLUDING LEAP, PEAP, EAP-TLS, EAP-TTLS, AND EAP-SIM TO YIELD MUTUAL AUTHENTICATION AND DYNAMIC, PER-USER, PER-SESSION ENCRYPTION KEYS MAC ADDRESS AND BY STANDARD 802.11 AUTHENTICATION MECHANISMS ENCRYPTION: SUPPORT FOR STATIC AND DYNAMIC IEEE 802.11 WEP KEYS OF 40 BITS AND 128 BITS TKIP ENCRYPTION ENHANCEMENTS: KEY HASHING (PER-PACKET KEYING), MESSAGE INTEGRITY CHECK (MIC) AND BROADCAST KEY ROTATION VIA WPA TKIP OR CISCO TKIP AES READY WITH FULL SUPPORT IN 2004 WIRELESS TECHNOLOGY :IEEE 802.11B/G INTERFACES/PORTS INTERFACES/PORTS :1 X RJ-45 10/100BASE-TX AUTO-SENSING UPLINK 1 X RJ-45 CONSOLE MANAGEMENT CHANNELS :11 CHANNEL(S)OPERATING IEEE 802.11B/G AMERICAS 3 CHANNEL(S)NON-OVERLAPPING MEDIA & PERFORMANCE DATA TRANSFER RATE :10MBPS ETHERNET 100MBPS FAST ETHERNET CONNECTIVITY MEDIA :TWISTED PAIR I/O EXPANSIONS EXPANSION SLOTS :2 X EXPANSION SLOTMODULES :1 X MINI PCISLOT DETAILS :1 X MINI PCI 1 X CARDBUS NETWORK & COMMUNICATION ANTENNA :2 X RP-TNC CONNECTORDATA TRANSFER RATE :10MBPS ETHERNET 100MBPS FAST ETHERNET FREQUENCY BAND/BANDWIDTH :2.412 GHZ TO 2.462 GHZ IEEE 802.11B/G FCCPROTOCOLS :BOOTP DHCP HTTP FTP TFTP TKIP ARP RECEIVER SENSITIVITY :-95 DBM - 1MBPS IEEE 802.11B -91 DBM - 2MBPS IEEE 802.11B -89 DBM - 5.5MBPS IEEE 802.11B -90 DBM - 6MBPS IEEE 802.11G -84 DBM - 9MBPS IEEE 802.11G -88 DBM - 11MBPS IEEE 802.11B -82 DBM - 12MBPS IEEE 802.11G -80 DBM - 18MBPS IEEE 802.11G -77 DBM - 24MBPS IEEE 802.11G -73 DBM - 36MBPS IEEE 802.11G -72 DBM - 48MBPS IEEE 802.11G -72 DBM - 54MBPS IEEE 802.11G STACKABLE :NOT APPLICABLETRANSMIT POWER :30 MW IEEE 802.11G 15 DBM IEEE 802.11G 20 MW IEEE 802.11G 13 DBM IEEE 802.11G 10 MW IEEE 802.11G 10 DBM IEEE 802.11G 5 MW IEEE 802.11G 7 DBM IEEE 802.11G 1 MW IEEE 802.11G 0 DBM IEEE 802.11G ANTENNA RANGE :27 M@ 54MBPS INDOORS IEEE 802.11G 29 M@ 48MBPS INDOORS IEEE 802.11G 30 M@ 36MBPS INDOORS IEEE 802.11G 43 M@ 24MBPS INDOORS IEEE 802.11G 55 M@ 18MBPS INDOORS IEEE 802.11G 64 M@ 12MBPS INDOORS IEEE 802.11G 76 M@ 9MBPS INDOORS IEEE 802.11G 91 M@ 6MBPS INDOORS IEEE 802.11G 76 M@ 54MBPS OUTDOORS IEEE 802.11G 183 M@ 18MBPS OUTDOORS IEEE 802.11G 396 M@ 6MBPS OUTDOORS IEEE 802.11G CHANNELS :11 CHANNEL(S)OPERATING IEEE 802.11B/G AMERICAS 3 CHANNEL(S)NON-OVERLAPPING WIRELESS TECHNOLOGY :IEEE 802.11B/G MANAGEMENT & PROTOCOLS SECURITY :VIRTUAL LAN (VLAN) SUPPORT: ALLOWS SEGMENTATION OF UP TO 16 USER GROUPSPROTOCOLS :BOOTP DHCP HTTP FTP TFTP TKIP ARP OPERATING SYSTEM :CISCO 1200 SERIES IOS WIRELESS LAN STATUS INDICATORS :THREE INDICATORS ON THE TOP PANEL REPORT: ASSOCIATION STATUS OPERATION ERROR/WARNING FIRMWARE UPGRADE CONFIGURATION NETWORK/MODEM RADIO STATUSMANAGEMENT :TELNET SNMP PROCESSOR & CHIPSET PROCESSOR :1 X IBM POWERPC405 200MHZ MEMORY MEMORY :16MB RAM INSTALLED 8MB FLASH MEMORY INSTALLED CONTROLS/INDICATORS CONTROLS :DUPLEX-MODE SWITCHSTATUS INDICATORS :THREE INDICATORS ON THE TOP PANEL REPORT: ASSOCIATION STATUS OPERATION ERROR/WARNING FIRMWARE UPGRADE CONFIGURATION NETWORK/MODEM RADIO STATUS POWER DESCRIPTION INPUT VOLTAGE :90 V ACTO 240 V AC ¦10% POWER SUPPLY UNIVERSAL 48 V DC ¦10% DEVICE POWER SUPPLY :AC EXTERNAL POWER CONSUMPTION :6W OPERATING ENVIRONMENTAL CONDITIONS HUMIDITY :10% TO 90% NON-CONDENSING OPERATINGTEMPERATURE :-20 ¦C TO 55 ¦C OPERATING PHYSICAL CHARACTERISTICS DIMENSIONS :4.22CM HEIGHT X 16.67CM WIDTH X 18.37CM DEPTH 5.53CM HEIGHT X 16.67CM WIDTH X 18.37CM DEPTH - WITH MOUNTING BRACKET SHIPPING DIMENSIONS :11.43CM HEIGHT X 24.13CM WIDTH X 43.81CM DEPTHSHIPPING WEIGHT :2.11 KG WEIGHT :725.75 G 907.18 G - WITH MOUNTING BRACKET FORM FACTOR :WALL-MOUNTABLE CEILING-MOUNTABLE DESKTOP MISCELLANEOUS ADDITIONAL INFORMATION :UPGRADABLE TO IEEE 802.11A TECHNOLOGY NETWORK ARCHITECTURE TYPE: INFRASTRUCTURE, STAR TOPOLOGY WIRELESS MEDIUM: ORTHOGONAL FREQUENCY DIVISION MULTIPLEXING (OFDM) DIRECT SEQUENCE SPREAD SPECTRUM (DSSS) SECURITY :VIRTUAL LAN (VLAN) SUPPORT: ALLOWS SEGMENTATION OF UP TO 16 USER GROUPSPACKAGE CONTENTS :CISCO AIRONET 1200 SERIES ACCESS POINT CISCO AIRONET 1200 SERIES POWER MODULE (UNIVERSAL POWER SUPPLY) QUICK START GUIDE: CISCO AIRONET 1200 SERIES ACCESS POINTS CISCO PRODUCT REGISTRATION AND CISCO DOCUMENTATION FEEDBACK CARDS S12W7K9-12213JA: CISCO 1200 SERIES IOS WIRELESS LANOPERATING SYSTEM :CISCO 1200 SERIES IOS WIRELESS LAN CERTIFICATIONS & STANDARDS :SAFETY: UL 1950 CSA 22.2 NO. 950-95 IEC 60950 EN 60950 RADIO APPROVALS: FCC PART 15.247 RSS-210 (CANADA) EMI AND SUSCEPTIBILITY (CLASS B): FCC PART 15.107 AND 15.109 ICES-003 (CANADA) SECURITY: 802.1X AND TKIP WPA AES READY OTHER: IEEE 802.1P IEEE 802.3 IEEE 802.11B IEEE 802.11G IEEE 802.11E IEEE 802.11 FCC BULLETIN OET-65C RSS-102 SNMP COMPLIANCE: MIB I MIB IIMANAGEMENT :TELNET SNMPSYSTEM REQUIREMENTS :ANTENNA PURCHASE IS REQUIRED FOR THE DEVICE TO WARRANTY STANDARD WARRANTY :1 YEAR(S) AIR-AP1231G-A-K9 ACCESS POINT CISCO SYSTEMS AIRONET 1231 C/ 1 SLOT CA TAGS DE AIR-AP1231G-A-K9: AIR-AP1231G-A-K9
