Especificações Técnicas

AIR-AP1262N-T-K9 802.11A/G/N STANDALONE AP; EXT ANT; T REG DOMAIN EXTERNAL ANTENNA (SOLD SEPARATELY) CISCO OFFERS THE INDUSTRYS BROADEST SELECTION OF 802.11N ANTENNAS DELIVERING OPTIMAL COVERAGE FOR A VARIETY OF DEPLOYMENT SCENARIOS.   INTERFACES 10/100/1000BASE-T AUTOSENSING (RJ-45) MANAGEMENT CONSOLE PORT (RJ-45) INDICATORS STATUS LED INDICATES BOOT LOADER STATUS, ASSOCIATION STATUS, OPERATING STATUS, BOOT LOADER WARNINGS, AND BOOT LOADER ERRORS ENVIRONMENTAL NONOPERATING (STORAGE) TEMPERATURE: -40 TO 185F (-40 TO 85C) OPERATING TEMPERATURE: -4 TO 131F (-20 TO 55C) OPERATING HUMIDITY: 10 TO 90 PERCENT (NONCONDENSING) SYSTEM MEMORY 128 MB DRAM 32 MB FLASH INPUT POWER REQUIREMENTS AP1260: 44 TO 57 VDC POWER SUPPLY AND POWER INJECTOR: 100 TO 240 VAC; 50 TO 60 HZ POWERING OPTIONS 802.3AF ETHERNET SWITCH CISCO AP1260 POWER INJECTORS (AIR-PWRINJ4) CISCO AP1260 LOCAL POWER SUPPLY (AIR-PWR-B) POWER DRAW AP1260: 12.95 W NOTE: WHEN DEPLOYED USING POWER OVER ETHERNET (POE), THE POWER DRAWN FROM THE POWER SOURCING EQUIPMENT WILL BE HIGHER BY SOME AMOUNT DEPENDENT ON THE LENGTH OF THE INTERCONNECTING CABLE. THIS ADDITIONAL POWER MAY BE AS HIGH AS 2.45W, BRINGING THE TOTAL SYSTEM POWER DRAW (ACCESS POINT CABLING) TO 15.4W. COMPLIANCE STANDARDS SAFETY: UL 60950-1 CAN/CSA-C22.2 NO. 60950-1 UL 2043 IEC 60950-1 EN 60950-1 RADIO APPROVALS: FCC PART 15.247, 15.407 RSS-210 (CANADA) EN 300.328, EN 301.893 (EUROPE) ARIB-STD 33 (JAPAN) ARIB-STD 66 (JAPAN) ARIB-STD T71 (JAPAN) AS/NZS 4268.2003 (AUSTRALIA AND NEW ZEALAND) EMI AND SUSCEPTIBILITY (CLASS B) FCC PART 15.107 AND 15.109 ICES-003 (CANADA) VCCI (JAPAN) EN 301.489-1 AND -17 (EUROPE) EN 60601-1-2 EMC REQUIREMENTS FOR THE MEDICAL DIRECTIVE 93/42/EEC IEEE STANDARD: IEEE 802.11A/B/G, IEEE 802.11N 2.0, IEEE 802.11H, IEEE 802.11D SECURITY: 802.11I, WI-FI PROTECTED ACCESS 2 (WPA2), WPA 802.1X ADVANCED ENCRYPTION STANDARDS (AES), TEMPORAL KEY INTEGRITY PROTOCOL (TKIP) EAP TYPE(S): EXTENSIBLE AUTHENTICATION PROTOCOL-TRANSPORT LAYER SECURITY (EAP-TLS) EAP-TUNNELED TLS (TTLS) OR MICROSOFT CHALLENGE HANDSHAKE AUTHENTICATION PROTOCOL VERSION 2 (MSCHAPV2) PROTECTED EAP (PEAP) V0 OR EAP-MSCHAPV2 EXTENSIBLE AUTHENTICATION PROTOCOL-FLEXIBLE AUTHENTICATION VIA SECURE TUNNELING (EAP-FAST) PEAPV1 OR EAP-GENERIC TOKEN CARD (GTC) EAP-SUBSCRIBER IDENTITY MODULE (SIM) MULTIMEDIA: WI-FI MULTIMEDIA (WMM) OTHER: FCC BULLETIN OET-65C RSS-102 AIR-AP1262N-T-K9 ACCESS POINT CISCO AIRONET 1262N TAGS DE AIR-AP1262N-T-K9: AIR-AP1262N-T-K9, AIR-AP1262N, AP1262N, AIRONET 1262, CISCO, CISCO SYSTEMS
